DESCRIPTION:

Reinforced Asbestos rubber Sheet is made from selected asbestos fiber, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields. with both graphite coating , reinforced by wire mesh with both graphite coating.

Reinforced Asbestos rubber Sheet with Wire Mesh

PARAMETER:

Item	Style
	RAS500	RAS500G	RAS500MG
Tensile strength≥Mpa	19	19	25
Aging coefficient	0.9	0.9	0.9
Loss on ignition ≤%	28	28	28
Compressibility ≥%	12±5	12±5	12±5
Recovery ≥%	45	45	45
Density g/cm3	1.8~2.0	1.8~2.0	2.0~2.2
Tmax:  ℃	500	550	550
Pmax:  Mpa	12.0	12.0	20
Normal color	Purple red	Graphite	Graphite
Resistance to media	Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure.

DIMENSION:
