Reinforced Asbestos Rubber Sheet

Reinforced Asbestos Rubber Sheet

  • Item No. 351
  • Insert Wire Mesh
  • Product description: Reinforced Asbestos Rubber Sheet from FEITE sealing sheets
  • INQUIRY

DESCRIPTION:

Reinforced Asbestos rubber Sheet is made from selected asbestos fiber, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields. with both graphite coating , reinforced by wire mesh with both graphite coating.

Reinforced Asbestos rubber Sheet with Wire Mesh


PARAMETER:

Item
Style
RAS500
RAS500G
RAS500MG
Tensile strength≥Mpa
19
19
25
Aging
coefficient
0.9
0.9
0.9
Loss on ignition
≤%
28
28
28
Compressibility
≥%
12±5
12±5
12±5
Recovery
≥%
45
45
45
Density g/cm3
1.8~2.0
1.8~2.0
2.0~2.2
Tmax:  ℃
500
550
550
Pmax:  Mpa
12.0
12.0
20
Normal color
Purple red
Graphite
Graphite
Resistance
to media
Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure.
Also available with anti-stick

DIMENSION:

Thickness:  0.4~6mm
2000×1500mm;  1500×4000mm;
1500×1500mm;  1500×1000mm;
1270×1270mm;  3810×1270mm
New:  3810×2700mm
