Reinforced Graphite Gasket

Item No. 130
Reinforced Graphite
Product description: Reinforced Graphite Gaskets from FEITE sealing gaskets
INQUIRY

DESCRIPTION:

Reinforced Graphite Gasket is made from graphite as homogeneous, reinforced by metal mesh, foil or tanged metal. It offers excellent sealing capabilities such as thermal stability, self-lubrication, corrosion resistance, without being brittle and aging etc.,under extreme conditions with a longer life and less maintenance.

Graphite Gasket

Gasket Style	130	130P	130T	130M
Without eyelet	130	130P	130T	130M
With inner eyelet	130 IR	130P IR	130T IR	130M IR
With outer eyelet	130 CR	130P CR	130T CR	130M CR
With I & O eyelets	130 IC	130P IC	130T IC	130M IC
Insert material	None	SS304、316 etc	SS304、316、CS	CS、304/316
		Foil	Tanged	Mesh
		0.05mm	0.1mm,0.25mm-CS	0.1mm

APPLICATION & PROPERTIES:

Various shapes are available, used in petrochemical, mining, vessels, boilers, piping and duct, pumps and valves, flanges etc. Suitable for steam, mineral oils, heat transfer oils, hydraulic oil, fuel, water, seawater, freshwater etc.

Sheet Style	130	130P	130T	130M
Compressibility	30%	15~35%	15~35%	15~35%
Recovery	≥10%	≥20%	≥20%	≥20%
Pressure	40bar	200bar	300bar	200bar
Density g/cm3	0.7; 1.0	1.0	1.0	1.0
Temperature0C	-240~550	-240~550	-240~550	-240~550
PH	0~14	0~14	0~14	0~14

Graphite properties:

Item	Tolerance of density	C≥%	Tensile strength	Sulphur content	Chlorine content	Stress relaxation	Ignition loss
Industrial	±0.06 g/cm3	98	4 Mpa	<1000ppm	<50ppm	10%	2.0≤%
Nuclear	±0.05 g/cm3	99.5	5 Mpa	<700ppm	<35ppm	10%	0.5≤%
