Reinforced Non-Asbestos Beater Sheet

  • Item No. 333
  • Product description: Reinforced Non-Asbestos Beater Sheet from FEITE sealing sheets
  • INQUIRY

DESCRIPTION:

It is made of Non-asbestos beater sheet reinforced with tanged 0.18-0.25mm Carbon Steel/TIN plated. It is extensively applied in manufacturing various motor gaskets. It is a new material that will substitute asbestos products. The product has excellent performance in dilatability, sealing equality and long life etc., Mainly applied in automobile farming machine, motorcycle and engineering etc., it is also can be used in high strength gaskets and cylinder gaskets etc.

CONSTRUCTION:

Can be made of asbestos emulsion sheet reinforced with tanged 0.18-0.25mm Carbon Steel/TIN Plated.

PARAMETER:

Item
Style
333
Density          g/cm3
1.30~1.50
Tensile strength   ≥Mpa
12.7
Compressibility ≥%
13±5
Recovery      ≥%
40
Sealing performance
<0.5cm3/min
Performance of heat-resistance
150-300°C
Normal colour: Black, Gray, Graphite etc.
Available with SS304. wire mesh insertion
Also available with anti-stick silicon resin
or graphite coating


DIMENSIONS:

500×1000mm;  500×1200mm;  500×1500mm;
510×1016mm;  510×1530mm;
1000×1000mm; 1000×1500mm;
Thickness:  1.0~2.4mm
