Description
The style RX Ring Joint Gasket is an adaptation of the standard style R which energizes on assembly. The RX is designed to fit the same groove design as a standard style R, making the joints interchangeable.
Consideration should be given to the difference in finished make-up distance.
The modified design uses an energizing on assembly effect with improves the efficiency of the seal.
Tolerances (Inches)
> "A" Width of ring: +0.008-0.008
> "H" Height of ring: +0.008-0.000
> "OD" Outer dimension of ring: +0.020,-0.000
> "23o" Angle: +/- 1/2o
Standard
Standard style R ring type joints are manufactured in accordance with both API 6A and ASME B16.20 size and ratings. Available in both oval and octagonal configurations, both types are interchangeable on the modern octagonal type grooved flanges.
As with all metal ring type joints including style RX, it is recommended to replace the ring when flange connection is broken.
